Memory
Flash 4 GB
RAM 1 GB
Processor
Processor Quad-core RISC
I/O Port
SD Card Slot microSD × 1
USB Host USB 2.0 × 1
Ethernet Port LAN 1: 10/100/1000 Base-T × 1
LAN 2: 10/100 Base-T × 1
COM Port N/A
RS-485 Dual Isolation N/A
CAN Bus N/A
HDMI max. resolution 1920 x 1080
Audio Output HDMI Audio Output
RTC
RTC Built-in
Power
Input Power 24±20%VDC
Power Isolation Built-in
Power Consumption 850mA@24VDC
Voltage Resistance 500VAC (1 min.)
Isolation Resistance Exceed 50MΩ at 500VDC
Specification
PCB Coating Yes
Enclosure Plastic
Dimensions WxHxD 29.8 × 130 × 115 mm
Weight Approx. 0.24 kg
Mount 35mm DIN rail mounting
Environment
Protection Structure IP20
Storage Temperature -20° ~ 60°C (-4° ~ 140°F)
Operating Temperature 0° ~ 50°C (32° ~ 122°F)
Relative Humidity 10% ~ 90% (non-condensing)
Altitude (Air Pressure) 3,000 m
Vibration Endurance 10 to 25Hz (X, Y, Z direction 2G 30 minutes)
Certificate
CE CE marked
UL cULus Listed
Software
Browser Chromium 132 (Upgradable)*
Weincloud EasyAccess 2.0 (Optional)
* The built‐in browser does not support websites requiring Java Applets or the Java SDK.
* For best compatibility, use websites developed with standard HTML5.
* The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
