I/O Port | |
---|---|
Cable Connector | 1 |
Wiring Terminal | 2 |
Specification | |
Enclosure | Plastic |
Dimensions WxHxD | 157.9x 75.9 x 55.2 mm |
Panel Cutout | 119.4 x 29.95 mm |
Weight | Approx. 0.2 kg |
Mount | Use six M4 screws, mounting hole size is 4.6 mm |
Environment | |
Protection Structure | IP66 Compliant Front Side |
Storage Temperature | -20° ~ 60°C (-4° ~ 140°F) |
Operating Temperature | 0° ~ 50°C (32° ~ 122°F) |
Relative Humidity | 10% ~ 90% (non-condensing) |
Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
Certificate | |
CE | CE marked |
UL | N/A |
